Engine and transmission
Displacement 449.0 ccm (27.40 cubic inches)
Engine type Single cylinder, four-stroke
Engine details Titanium-valves
Compression 13.0:1
Bore x stroke 97.0 x 60.9 mm (3.8 x 2.4 inches)
Valves per cylinder 4
Fuel system Injection. Mikuni® fuel injection, 44mm
Fuel control Double Overhead Cams/Twin Cam (DOHC)
Ignition TCI: Transistor Controlled Ignition
Lubrication system Wet sump
Cooling system Liquid
Gearbox 5-speed
Transmission type Chain (final drive)
Clutch Multiplate wet clutch

Chassis, suspension, brakes and wheels
Frame type Bilateral beam frame, aluminum
Rake (fork angle) 26.9°
Trail 119 mm (4.7 inches)
Front suspension KYB Speed-Sensitive System, inverted fork: fully adjustable
Front wheel travel 310 mm (12.2 inches)
Rear suspension KYB® single shock; fully adjustable
Rear wheel travel 318 mm (12.5 inches)
Front tire 80/100-21
Rear tire 120/80-19
Front brakes Single disc. Hydraulic.
Diameter 270 mm (10.6 inches)
Rear brakes Single disc. Hydraulic.
Diameter 240 mm (9.4 inches)
Seat Long, two-tone, motocross-style seat

Physical measures and capacities
Weight incl. oil, gas, etc 111.1 kg (245.0 pounds)
Seat height 965 mm (38.0 inches) If adjustable, lowest setting.
Overall height 1285 mm (50.6 inches)
Overall length 2184 mm (86.0 inches)
Overall width 826 mm (32.5 inches)
Ground clearance 330 mm (13.0 inches)
Wheelbase 1486 mm (58.5 inches)
Fuel capacity 6.06 litres (1.60 US gallons)
Oil capacity 1.00 litres (1.06 US quarts)
